KB3000L
KOMPA
Silicone material
0.5mm-5mm
7-14 days
0.4–0.9 g/cm³
China
ISO9001, ISO14001, ISO45001, IATF16949, EN45545-2, UL94-V0, NSF61, UL157-2007 Gaskets and Seals. CE, ROHS, PAHS, REACH
Product Description
KOMPA Silicone Sheet is a high-performance solid silicone rubber material manufactured from High Consistency Rubber (HCR) technology. Unlike silicone foam materials, this product features a dense and non-cellular structure, providing superior mechanical strength, dimensional stability, electrical insulation, and long-term heat resistance.
Designed for industrial sealing, thermal protection, electrical insulation, and structural applications, KOMPA solid silicone sheets are widely used in EV battery systems, ESS cabinets, electrical equipment, rail transit, industrial machinery, and outdoor environments.
Compared with liquid silicone molded products, solid silicone sheets offer higher production efficiency for sheet and roll materials, easier die-cut processing, and more economical large-area applications.
Designed to maintain stable physical performance across a wide operating temperature range.
Continuous operating temperature: −60°C to +230°C
Short-term peak temperature: up to +250°C
Excellent thermal aging resistance
Suitable for high-temperature industrial environments.
Dense silicone structure delivers stronger physical performance than silicone foam materials.
Advantages:
Higher tensile strength
Better dimensional stability
Long-term compression durability
Strong tear resistance
Ideal for demanding sealing and structural applications.
Silicone chemistry provides natural resistance against environmental exposure.
Features:
UV resistant
Ozone resistant
Moisture resistant
Outdoor aging resistance
Suitable for long service life.
KOMPA solid silicone sheet supports electrical protection applications.
Benefits:
High dielectric strength
Stable electrical insulation
Arc resistance
Suitable for electrical and energy applications.
Available in multiple conversion formats.
Processing options:
Roll material
Sheet material
Die-cut parts
Adhesive backing
Slitting
Laminating
Solid Silicone Rubber Plate KB3000S TDS.pdf
| Property | KB3100S Standard | KB3200S Flame-Retardant | KB3300S Cryogenic Type | KB3400S High-Temperature | KB3500S Ceramifiable Type | Test Standard |
|---|---|---|---|---|---|---|
| Flame Retardancy | – | V-0 / HF-1 | – | – | V-0 / HF-1, Surface Ceramification | UL94 |
| Hardness (Shore A) | 20–75 | 30–75 | 30–75 | 30–75 | 30–75 | ASTM D2240 |
| Tensile Strength (MPa) | ≥2.0 | ≥5.0 | ≥2.0 | ≥2.0 | ≥3.0 | ASTM D412 |
| Elongation at Break (%) | ≥200 | ≥200 | ≥200 | ≥200 | ≥200 | ASTM D412 |
| Density (g/cm³) | 1.1 ± 0.5 | 1.4 ± 0.5 | 1.1 ± 0.5 | 1.1 ± 0.5 | 1.6 ± 0.5 | ASTM D1056 |
| Temperature (°C) | -55 to 200 | -55 to 200 | -55 to 200 | -55 to 200 | No cracking after 30 min at 1000°C | ASTM D412 |
| Environmental Testing | PASS | RoHS 2.0 / REACH | ||||
| Thickness (mm) | 0.5–5.0 | ASTM D374 | ||||
| Color | Black, Red, Customized Color | Visual | ||||
| Surface Treatment | Glossy Finish, Matte Finish, Textured (Fabric-Like) Finish | Visual | ||||
| Base Material | Polyester Fabric, Nylon Fabric, Glass Fiber Fabric, PTFE Fabric | Visual | ||||
Used for:
Electrical insulation
Structural buffering
Thermal protection
Applications include:
Cabinet sealing
Environmental protection
Electrical separation
Suitable for:
Dust sealing
High-temperature protection
Vibration absorption
Typical uses:
Electrical insulation pads
Protective barriers
Device sealing
Applied in:
Rail transit
Automotive systems
Outdoor equipment
To ensure the quality and safety of your order, KB3000L solid silicone sheets are packaged with care and precision, ready for both domestic and international shipment.
Individually stacked with protective interleaving (PE film or kraft paper)
Bundled in moisture-proof wrapping
Packed in export-grade cartons or wooden cases (on request)
Rolled with core support to prevent deformation
Wrapped in stretch film and bubble wrap for shock protection
Secured in reinforced cartons or on pallets for bulk orders
Separated by layers or trays to avoid damage
Bagged and boxed with clear labeling by part number or project
Palletizing for bulk shipments
Heat-shrink wrapping for sea freight
Labeling with product code, lot number, and QC status
With reliable packaging and global shipping experience, KOMPA ensures your silicone sheets arrive safely and ready for production.
Consistent thickness, hardness, and surface finish
Clean-cut edges, ready for fabrication or direct use
For testing and evaluation before mass production orders.
Sheets, rolls, or die-cut parts per your design
Thickness from 0.5 mm to 5 mm
Adhesive backing (single or double-sided)
Fabric reinforcement (on request)
Flame-retardant
Clean PE film wrap or kraft paper interleaved
Export-grade carton or pallet packaging for safe delivery
Material Data Sheet (TDS)
REACH, RoHS, and UL compliance certificates (if applicable)
Application guidance from our engineering team
All pads are 100% inspected, RoHS/REACH compliant, and manufactured under ISO 9001 quality systems.
KOMPA is a trusted innovator in silicone-based insulation materials technologies. We combine materials science expertise with precision manufacturing to deliver solutions that meet the most demanding requirements in EV battery systems, energy storage, automotive electronics, and industrial applications.
Over 8 years of experience in silicone materials
In-house R&D for continuous product innovation
ISO 9001-certified production with full traceability
Consistent performance, certified by third-party labs (UL, RoHS, REACH)
Tailored solutions: thickness, hardness, die-cutting
Technical support from prototype to mass production
Long-term cooperation with leading automotive and energy OEMs
Trusted by clients in Europe, North America, and Southeast Asia
Our Key Partners Include
Huawei – Global leader in communications, smart devices, and energy solutions
ZENERGY – Trusted supplier specializing in new energy battery systems
SAIC Motor – One of China’s largest and most innovative automotive manufacturers
Dongfeng Motor – Leading state-owned company in commercial and passenger vehicles
CRRC – World’s largest manufacturer of rail transit equipment and systems
CALB – Global innovator in lithium battery technology and energy storage solutions
Their trust speaks for our quality, reliability, and engineering excellence.
Choose KOMPA—where material innovation meets engineering precision.
We understand that every application has unique requirements. That’s why our KB3000S solid silicone sheets are available with a wide range of customization options to meet your exact needs.
Thickness range: 0.5 mm to 5 mm
Custom sheet sizes or roll lengths
Precision tolerance control for tight-fitting applications
Standard colors: Red, Gray, White
Custom colors available upon request (Pantone matching available)
Single-sided or double-sided PSA (Pressure-Sensitive Adhesive)
High-temp resistant adhesives available
Easy-peel liners for fast assembly
Fabric-reinforced silicone (fiberglass, polyester mesh)
For increased dimensional stability and tear resistance
Flame-retardant (UL94 V-0 grade)
FDA-compliant for food or medical applications
Electrically conductive or anti-static grades
UV, ozone, and chemical resistance tailored to your environment
Custom gaskets, pads, and components
CNC cutting, kiss-cutting, and laser fabrication
Low-volume prototyping to high-volume production
With flexible production and in-house engineering, KOMPA delivers silicone sheet solutions that fit your product—not the other way around.
Solid Silicone Sheet KB3000S is used for sealing, insulating, and protecting components in high-temperature and harsh environments. It is specifically designed for applications requiring excellent thermal stability, long-term compression resistance, and reliable electrical insulation. Thanks to its durable silicone formulation and consistent mechanical performance, KB3000S is ideal for:
EV battery packs and energy storage enclosures
Automotive engine compartments, sensors, and connectors
Power electronics such as converters and control modules
High-voltage electrical equipment and insulation panels
Industrial machinery and oven sealing systems
Its solid structure and customizable form make it suitable for precision gaskets, pads, and protective barriers—helping reduce mechanical stress, resist environmental aging, and ensure stable operation over time.
Yes, please download here
Choosing the right solid silicone sheet depends on your application’s mechanical, thermal, and environmental demands. KB3000S is available in multiple configurations to suit a wide range of industrial and electronic uses.
Use KB3000S for applications ranging from -60°C to +200°C
Ideal for environments with high heat, thermal cycling, or cold starts
Sheets (0.5–5.0 mm): Ideal for tight tolerances and insulation layers
Choose based on gap-filling and compressive force requirements
Available in 25–75 Shore A
Softer grades for better surface conformity
Harder grades for dimensional stability and structural support
Smooth or textured surface available
Red, Gray, or White standard colors; custom colors optional
Consider visibility, aesthetics, or color-coding in your system
Ask for flame-retardant versions if needed
Electrical insulation? Confirm dielectric breakdown values
Exposure to chemicals? Request enhanced chemical-resistant grades
If you’re unsure, our engineers can help recommend the right thickness, hardness, and material grade for your application. Custom die-cutting, adhesive backing, and reinforcement options are also available. Contact KOMPA’s technical team for personalized guidance and samples.
